Copper Bar Rod grades C60800, C63020, C65500, and C68700 are high-performance copper alloys, each offering unique properties tailored to specific industrial needs. These alloys are valued for their excellent mechanical properties, corrosion resistance, and ease of machinability.
- C60800 (Aluminum Bronze): Known for high strength and excellent wear resistance.
- C63020 (Nickel-Aluminum Bronze): Offers outstanding corrosion resistance in marine environments.
- C65500 (High-Silicon Bronze): Provides superior thermal and electrical conductivity.
- C68700 (Arsenical Brass): Combines good mechanical strength with resistance to dezincification and stress corrosion cracking.
Key Features:
- High Strength and Durability: Withstand mechanical stress and harsh environments.
- Corrosion Resistance: Excellent performance in seawater, industrial, and chemical applications.
- Thermal and Electrical Conductivity: Suitable for heat transfer and conductive applications.
- Versatility: Wide range of shapes and finishes available for various applications.
Applications:
- C60800: Gears, bearings, bushings, and high-load industrial machinery components.
- C63020: Propellers, pumps, valves, and marine hardware.
- C65500: Electrical connectors, heat exchanger components, and welding electrodes.
- C68700: Condenser tubes, decorative elements, and plumbing fittings.
Technical Specifications:
Chemical Composition:
| Element | C60800 (%) | C63020 (%) | C65500 (%) | C68700 (%) |
|---|
| Copper (Cu) | 78 – 82 | 77 – 81 | 96.2 – 97.8 | 76 – 80 |
| Aluminum (Al) | 8.5 – 10.5 | 9.0 – 11.0 | ≤0.50 | ≤0.05 |
| Nickel (Ni) | ≤0.50 | 4.0 – 5.5 | – | – |
| Silicon (Si) | – | – | 2.8 – 3.5 | – |
| Zinc (Zn) | – | – | – | Balance |
| Others | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.50 |
Mechanical Properties:
| Property | C60800 | C63020 | C65500 | C68700 |
|---|
| Tensile Strength (MPa) | 620 – 850 | 690 – 850 | 350 – 550 | 380 – 540 |
| Yield Strength (MPa) | ≥275 | ≥280 | ≥100 | ≥100 |
| Elongation (%) | ≥15 | ≥15 | ≥25 | ≥20 |
| Hardness (HB) | 130 – 200 | 150 – 220 | 90 – 120 | 80 – 110 |
Physical Properties:
| Property | Value |
|---|
| Density (g/cm³) | 7.7 – 8.5 |
| Electrical Conductivity (%IACS) | 9 – 40 |
| Thermal Conductivity (W/m·K) | 80 – 150 |
| Melting Point (°C) | 930 – 1050 |
| Item | Copper bar ,copper rod |
| Material | C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920, |
| C10930,C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300, |
| C12500,C14200,C14420,C14500,C14510,C14520,C14530,C17200,C19200, |
| C21000,C23000,C26000,C27000,C27400,C28000,C33000,C33200,C37000, |
| C44300,C44400,C44500,C60800,C63020,C65500,C68700,C70400,C70620, |
| C71000,C71500,C71520,C71640,C72200,etc |
| Standard | ASTMB152,B187,B133,B301,B196,B441,B465,JISH3250-2006, |
| GB/T4423-2007,etc |
| Diameter | 3mm~800mm |
| Length | 5.8m,6m,or as required |
| Contact | If you have any question,please feel free to contact me |
| Package | Standard export seaworthy package,suit for all kinds of transport,or as required. |
| Container | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) |
| Size | 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) |
| 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
| Price term | Ex-Work,FOB,CNF,CFR,CIF,etc |
| Application | Copper bar is widely used in boat building,War industry, Car industry and communication |
| industry where the components need good wear proof and great corrosion resistance |
